Material:SS304/316L
Claw:PA66 (Nylon)
Hermetic:NBR
O-Ring:NBR
Thread size:M thread, PG thread, G thread, NPT thread
Working temperature:Static -40 ℃ ~ +100 ℃ , short time can be up to + 120 ℃
Protection Level:IP66
Features:Increase flood control external meter seal, with advanced CNC machine tools finishing materials made of flameproof bushings and inside and outside built-drogue proof function, good protective performance, with fast installation, safe and reliable armor.
| Model | GLAND SIZE | GL(mm) | Clamping Range(mm) | Across Flats'D" | Across Conrner"D" | Protrusion Lenhth"F" | |
| YKWS-A2-M20SS | M20 | 10 | 3.2 | 8.7 | 24 | 26.4 | 25.1 |
| YKWS-A2-M20S | M20 | 10 | 6.1 | 11.7 | 24 | 26.4 | 25.1 |
| YKWS-A2-M20 | M20 | 10 | 6.5 | 14 | 27 | 29.7 | 27.2 |
| YKWS-A2-M25 | M25 | 10 | 11.1 | 20 | 36 | 39.6 | 35.5 |
| YKWS-A2-M32 | M32 | 10 | 17 | 26.3 | 41 | 45.1 | 34.2 |
| YKWS-A2-M40 | M40 | 15 | 23.5 | 32.2 | 50 | 55 | 35.1 |
| YKWS-A2-M50S | M50 | 15 | 31 | 38.2 | 55 | 60.5 | 32 |
| YKWS-A2-M50S | M50 | 15 | 35.6 | 44 | 60 | 66 | 36.3 |
| YKWS-A2-M63S | M63 | 15 | 41.5 | 49.9 | 70.5 | 77.6 | 33.5 |
| YKWS-A2-M63 | M63 | 15 | 47.2 | 55.9 | 75 | 82.5 | 35.9 |
| YKWS-A2-M75S | M75 | 15 | 54 | 61.9 | 84 | 92.4 | 34.2 |
| YKWS-A2-M75 | M75 | 15 | 61.1 | 67.9 | 84 | 92.4 | 40.6 |
| YKWS-A2-M90 | M90 | 24 | 66.6 | 79.9 | 108 | 118.8 | 58.3 |
| YKWS-A2-M100 | M100 | 24 | 76 | 91 | 123 | 135.3 | 55.2 |
| YKWS-A2-M115 | M115 | 24 | 86 | 97.9 | 133.4 | 146.7 | 65.2 |
| YKWS-A2-M130 | M130 | 24 | 97 | 114.9 | 152.4 | 167.6 | 73.9 |
