Material: UL approved PA6/PA66
Color: Black(RAL9005), Gray(RAL7035) map11
Thread: Metric, PG, G, NPT thread.
Working Temperature: -40℃ to 100℃
Function: Waterproof
Connect metal flexible conduit to provide strong pull-out strength and anti-vibration.
Model | Thread | AG(mm) Outer diameter | GL(mm) Thread Lengt | |
| 5/16 | YKWN-MNF-M16-AD15.8 | M16x1.5 | 16 | 10 |
| 3/8 | YKWN-MNF-M15-AD15.8 | M15x1.5 | 16 | 10 |
| 1/2 | YKWN-MNF-M20-AD21.2 | M20x1.5 | 20 | 10 |
| 3/4 | YKWN-MNF-M25-AD26.2 | M25x1.5 | 25 | 10 |
| 1 | YKWN-MNF-M32-AD34.5 | M32x1.5 | 32 | 10 |
| 1-1/4 | YKWN-MNF-M40-AD42.5 | M40x1.5 | 40 | 15 |
| 1-1/2 | YKWN-MNF-M50-AD48 | M50x1.5 | 50 | 15 |
| 2 | YKWN-MNF-M63-AD54.5 | M63x1.5 | 63 | 25 |
| 5/16 | YKWN-MNF-PG16-AD15.8 | PG16 | 22.5 | 10.8 |
| 3/8 | YKWN-MNF-PG16-AD15.8 | PG16 | 22.5 | 10.8 |
| 1/2 | YKWN-MNF-PG16-AD21.2 | PG16 | 22.5 | 13 |
| 3/4 | YKWN-MNF-PG21-AD28.5 | PG21 | 28.3 | 13 |
| 1 | YKWN-MNF-PG129-AD34.5 | PG129 | 37 | 15 |
| 5/16 | YKWN-MNF-G(NPT)1/2-AD15.8 | G(NPT)1/2 | 20.9 | 15 |
| 3/8 | YKWN-MNF-G(NPT)1/2-AD18.5 | G(NPT)1/2 | 20.9 | 15 |
| 1/2 | YKWN-MNF-G(NPT)1/2-AD21.2 | G(NPT)1/2 | 20.9 | 15 |
| 3/4 | YKWN-MNF-G(NPT)3/4-AD28.5 | G(NPT)3/4 | 26.4 | 15 |
| 1 | YKWN-MNF-G(NPT)1-AD34.5 | G(NPT)1 | 33.2 | 15 |
| 1-1/4 | YKWN-MNF-G(NPT)1-1/4-AD42.5 | G(NPT)1-1/4 | 41.9 | 15 |
| 1-1/2 | YKWN-MNF-G(NPT)1-1/2-AD48 | G(NPT)1-1/2 | 48 | 15 |
| 2 | YKWN-MNF-G(NPT)2-AD54.5 | G(NPT)2 | 60 | 15 |
