Material: SS304/316L
Color: Silver
O-Ring: NBR
Working temperature: -40℃ ～ +100℃ , short time can be up
Screw type for steel pipe or a joint with screw thread connecting piece can be external thread.
| Model | Adapted Hose Size | Inner Tooth Thread | NPT | Wrench Size (mm) | ||
| Metric | inch | Inch | Light Steel | |||
| YKWS-DPN12 | φ12 | 3/8" | G3/8" | C19 | NPT3/8" | 18/16 |
| YKWS-DPN15 | φ15 | 1/2" | G1/2" | C19 | NPT1/2" | 24/22 |
| YKWS-DPN20 | φ20 | 3/4" | G3/4" | C25 | NPT3/4" | 24/22 |
| YKWS-DPN25 | φ25 | 1" | G1" | C31 | NPT1" | 26 |
| YKWS-DPN32 | φ32 | 1 1/4" | G1 1/4" | C39 | NPT1 1/4" | 30 |
| YKWS-DPN38 | φ38 | 1 1/2" | G1 1/2" | C51 | NPT1 1/2" | 35 |
| YKWS-DPN51 | φ51 | 2" | G2" | C63 | NPT2" | 43 |
| YKWS-DPN64 | φ64 | 2 1/2" | G2 1/2" | C75 | NPT2 1/2" | 52 |
| YKWS-DPN75 | φ75 | 3" | G3" | NPT3" | 60 | |
| YKWS-DPN100 | φ100 | 4" | G4" | NPT4" | 75 | |
| YKWS-DPN125 | φ125 | 5" | G5" | NPT5" | 89/87 | |
| YKWS-DPN150 | φ150 | 6" | G6" | NPT6" | 102/97 | |
